Product Name: R Axis Manual Rotation Stage, Rotating Platform PX120-56

Share
Specification:

◆ Item Number: PX120-56

◆ Rotation Range: coarse 360° fine ±3°

◆ Diameter of Platform: Ø56mm

◆ Actuator Type: Fine Adjustment Screws in Side

◆ Graduations: 2°

◆ Readout: 0. 2°

◆ Adjust Distance:10"

◆ Surface Roundness:60μm

◆ Transversal Deviation: 30μm

◆ Parallelism:  60μm

◆ Material – Finish: Aluminum Alloy - Black-Anodized

◆ Load Capacity: 2Kgs

◆ Weight: 0.15kgs



R Axis Manual Rotation Stage, Rotating Platform PX120-56


Product details:
Advantage:

PDV has many different  specifications manual translation(linear) stage, including manual stage, linear stage, translation stage ,manual translation stage, Z axis lifting platform、Lab Jack、High-Load Vertical Stages, 360 degree rotation stage、Rotary Stage、Angle adjustment stage and so on .

We stock a large stock.



Service:
R Axis Manual Rotation Stage, Rotating Platform PX120-56
  • R Axis Manual Rotation Stage, Rotating Platform PX120-56
  • R Axis Manual Rotation Stage, Rotating Platform PX120-56
  • R Axis Manual Rotation Stage, Rotating Platform PX120-56
  • R Axis Manual Rotation Stage, Rotating Platform PX120-56
We can ship to you by UPS,FEDEX,DHL,TNT,EMS,other shipping terms can also be arranged according to specific requirements.
Shipping:
We can ship to you by UPS,FEDEX,DHL,TNT,EMS,other shipping terms can also be arranged according to specific requirements.
R Axis Manual Rotation Stage, Rotating Platform PX120-56
R Axis Manual Rotation Stage, Rotating Platform PX120-56
FAQ:
Note:

    We are glad that you can cooperate with us.,As the journey is far away, please be sure to see the parameters or communicate with our sales when selecting the product, Avoid buying wrong products to delay your use..
