| Item Number | PT-XY15 | |
| Structure | Travel Range | 15mm |
| Platform | 90mm × 90mm | |
| Bearing Construction | High Precise Grinding Screw (1mm of leading) | |
| Travel Guide | Crossed Roller Bearing | |
| Stepper Motor (1.8°) | 28STH51H-0674B | |
| Material | Aluminum Alloy - Black-Anodized | |
| Load Capacity | 10Kgs | |
| Weight | 3.2Kgs | |
| Accuracy | Design Resolution | 2.5μm/Pulse, Non-MS Driver0.125μm/Pulse, 20MS Driver |
| Velocity | 6mm/sec | |
| Repeatability | 1.5μm | |
| Absolute Accuracy | 5μm | |
| Straightness | 5μm | |
| Parallelization | 15μm | |
| Pitching | 50" | |
| Yawing | 25" | |
| Backlash | 2μm | |
| Lost Motion | 2μm | |
| Others | Scales (-G), Servo Motor (-D) | |
Product features
New construction ,new technology;the key index has up to the international level of the similar products by strictly inspection .This series products are used to laser precision processing,three dimensional scanning measurement system and so on .
Best-selling products
PDV offers high precision electric platform, high precision manual platform, optical plate, microscope bracket, long working distance objective, microscope lighting source, optical bench products for laboratory light path building.
we will provide excellent service and competitive price for you, we are expecting become your long-term partner in China.
X, Y Miniature Microscope Stage, 15mm Travel
◆ With RS232 Interface
◆ The Compact Size and High Performance a convert a Routine Microscope into a Highly Productive Asset.
◆ Universal Mounting Makes this Stage an Excellent Choice for Metrology and Inspection Applications.
◆ Combine Various Stages to Help youBuild a Wide Range of Multi-Axis. Systems from XY to XYZ.
◆ Stages Drove by Lead Screw in Both X and Y Axis, Crossed Roller Bearing Requires the High Load Capacity
