| Magnification | Standard:10X/30X, using optional eyepiece andauxiliary lens, it can extend to 5X~160X, |
| Objective | 1X、2X、3X、4X |
| Eyepiece | Wide field and high eyepiont eyepieceWF10X/23mm |
| Wide field and high eyepiont eyepieceWF15X/16mm | |
| Wide field and high eyepiont eyepieceWF20X/12mm | |
| Binocular head, 45°inclined,360°rotatable,interpupillary range 54~76mm, both two sidediopter adjustment(±5) | |
| Viewing Head | |
| Trinocular head, fixed light splitting 50% ：50% | |
| WorkingDistance | Standard:100mm, using optional auxiliary lens canexpand to 30mm-165mm |
| Auxiliary Lens | 0.5X/165mm、1.5X/45mm、2X/30mm |
| Focus arm | tension adjustable, adjust range 50mm |
| Stand | Pillar type sector stand |
| Pillar stand with top & bottom illumination. Bottomilluminator: halogen bulb 12V15W( brightnessadjustment )， Oblique lighting 12V/15W | |
| Pillar stand with top & bottom illumination. Bottomilluminator: fluorescent bulb 230V/8W ， Obliquelighting 12V/15W | |
| Other type stand, ring light and fluorescent light andfiber light for option. | |
| Photo device | Photo tube（with PK mount），3.2X photo eyepiece |
| TV device | 0.35X/0.5X/1.0X C-mount adapter |
| Others | Precision measurement platform, dark fieldcondenser, jewelry clip |
We have Processing equipment: CNC 10 sets, Lathe 8 sets, milling machine 11 sets. We have a group of experienced high-level processing technicians. Our products are sent to the Metrology Institute for random inspection every year regularly and issue inspection report.
Have the industry leading level of the designer, can strictly grasp the product design and processing precision.
We have experienced and skilled assembly master.
Our products from the design concept, the processing technology, the assembly technology omni-directional control.Provide high quality products for users.
If our standard products do not meet your requirements, we can customize them according to your requirements.
We are glad that you can cooperate with us.,As the journey is far away, please be sure to see the parameters or communicate with our sales when selecting the product, Avoid buying wrong products to delay your use..
