Product Name: Manual XYR Three-Axis Combination Stage Multidimensional Platform RD60

Share
Specification:

    RD60 manual multi-dimensional combination platform can carry out XY R multi-dimensional movement. The product is light in weight and small in size, and can be built into other products, which is convenient for operation and precise in product positioning. It has been recognized by many customers! If you are interested in our products, you can contact us at any time, we will give you a comprehensive product answer!

    RD60 Manual Multi-axis Stage Product parameters


    RD60

    RD80

    RD90

    Direction   of movement

    Three   directions of XYR axis

    Main   material

    Aluminum   alloy (black anode)

    Driving   mode

    Differential   head

    Platform   Size

    φ60

    φ80

    φ90

    Trip

    XY   axis ± 6.5mm θ axis: 360 ° coarse adjustment; ± 5 ° fine adjustment

    XY   axis ± 12.5mm θ axis: 360 ° coarse adjustment; ± 5 ° fine adjustment

    load

    29.4N(3kgf)

    39.2N(4kgf)

    29.4N(3kgf)

    Minimum   scale

    0.01mm

    Weight

    0.64kg

    1.57kg

    1.50kg



Product details:

RD60 Precision Manual Multi-Axis Stage
