High precision: The rollers and cams have a seamless fit, maintaining high segmentation accuracy and high torque while also being able to withstand heavy loads
High speed: High-precision rollers and cams completely avoid the formation of gaps, enabling the turntable to run at high speed and smoothly without vibration under acceleration or load
Customized extremely high load capacity: The maximum load it can withstand can reach 15 tons
Product parameters：
| Model | PT-HT100 | PT-HT150 | PT-HT200 |
| Dial size (mm | 130 | 185 | 360 |
| Central aperture (mm | 100 | 150 | 200 |
| Reduction ratio | 1:20 | 1:20 | 1:40 |
| Start-stop upper limit torque (Nm) | 585 | 1005 | 2821 |
| Static output torque (Nm | 850 | 1680 | 4017 |
| Allowable load | 200kg | 500kg | 1.5T |
| Maximum allowable output shaft speed (r/min) | <100 | <80 | <36 |
| Rated speed of the output shaft (r/min | 35 | 30 | 20 |
| Allowable radial load (N) on the output shaft | 4500 | 7150 | 12000 |
| Allowable inertial moment load (Nm | 220 | 250 | 120000 |
| Positioning accuracy (arcsec | ±5 | ±8 | ±8 |
| Repeat Positioning Accuracy (sec | ±5（0.001°） | ||
| Parallelism of the rotating platform (mm) | ±0.005（Customization is available as needed0.002~0.005) | ±0.01（Customization is available as needed0.002~0.005) | |
| Concentricity of the rotating platform (mm | ±0.005（Customization is available as needed0.002~0.005) | ±0.01（Customization is available as needed0.002~0.005) | |
| Precision life (h | 20000 | ||
| Protection grade | IP40 | ||
| Weight (kg | 20 | 40 | 120 |
Product size：
