This XYR motorized three-axis stage is composed of an motorized XY linear stage PT-XY15 and an motorized rotary stage PX110-60.
Product parameters:
Structure | Model Number | PX110-60 |
Angle range | 360° | |
Platform Size(mm) | φ60mm | |
Transmission Ratio | 45:1 or 90∶1 | |
Drive Mechanism | Worm Gear | |
Travel Guide | Bearing | |
Stepper Motor (1.8°) | 42BYG | |
Main Material | Aluminium Alloy | |
Surface Treatment | Anodizing blackening | |
Central Load | 30kg | |
Weight | 1.2kg | |
Accuracy | Resolution |
0.02°(Non-MS Driver) |
Speed | 50°/sec | |
Repeatability | 0.005°=18″ | |
Absolute Accuracy | 0.01°=36″ | |
Run-Out of Top Plate | 15μ | |
Backlash(μm) | 0.005°=18″ | |
Eccentricity | 5μ | |
Lost Motion | 0.005°=18″ | |
Parallelization | 80μ |
Model Number | PT-XY15 | |
Structure | Travel Range | 15mm |
Platform | 90mm × 90mm | |
Bearing Construction | High Precise Grinding Screw (1mm of leading) | |
Travel Guide | Crossed Roller Bearing | |
Stepper Motor (1.8°) | 28STH51H-0674B | |
Material | Aluminum Alloy - Black-Anodized | |
Load Capacity | 10Kgs | |
Weight | 3.2Kgs | |
Accuracy | Design Resolution | 2.5μm/Pulse, Non-MS Driver 0.125μm/Pulse, 20MS Driver |
Velocity | 6mm/sec | |
Repeatability | 1.5μm | |
Absolute Accuracy | 5μm | |
Straightness | 5μm | |
Parallelization | 15μm | |
Pitching | 50" | |
Yawing | 25" | |
Backlash | 2μm | |
Lost Motion | 2μm | |
Others | Scales (-G), Servo Motor (-D) | |
Precision Motorized Integral Linear Satge PT-XY15
Motorized Rotary Stage PX110-60
