Can be used in combination with the inertial piezoelectric platform link: Product Features:
https://www.pdvcn.com/nano-piezoelectric-platform/1526.html
https://www.pdvcn.com/nano-piezoelectric-platform/1525.html
■ Integrated grating sensor measurement circuit
■ Driving frequency: 2 kHz
■ Sawtooth wave driving, driving voltage: 0 - 150V
■ Supports more flexible control of the motor using a dedicated instruction set
■ Single channel, dual channel, quad channel up to multi-channel expansion
Product parameters:
| Model number | KZ-120 | |
| Digital control module | Control type | Proportional-Integral Control |
| Communication interface | RS232/485、Ethemet | |
| Control software | Specialized software | |
| Support functions | Automatic change detection, closed-loop control, customizable waveforms | |
| Sensor module | Sensor type | Raster sensor |
| Sensor resolution | 1nm (ms) | |
| Amplifier module | Output voltage | 0-150V |
| Drive voltage interface | DB15 | |
| Channel number | Channel 1 | |
| Peak frequency | 15W | |
| Current limit | Short-circuit protection | |
| Overheat protection | yes | |
| Other | Weight | 0.588KG |
| Length * Width * Height | 220*100*58mm | |
| Operating Voltage | DC24V | |
| Maximum Current | 1A | |
| Operating Temperature | -20-70℃ | |
